The welded wire mesh production process

The welded wire mesh production process, many customers are very interested, due to schedule and other reasons has been missed to come to the factory to find out. Here I will take you into Anping LINKLAND Metal Products Co., Ltd. welded wire mesh workshop, a close look at the production process of welded wire mesh.

As a construction, breeding and deep processing material, welded wire mesh has been used more and more in more life scenes. Welded wire mesh commonly used specifications are the following four: galvanized welded wire mesh; dip welded wire mesh; insulation welded wire mesh; stainless steel welded wire mesh. We are insulated welded wire mesh, for example, to see how welded wire mesh products specifically produced.

Insulated welded wire mesh using galvanized wire drawing as raw material, welded wire mesh precision welding, the general width of 0.914 meters, 1 meter, 1.2 meters, the length of the development with customer requirements, conventional 18 meters or 20 meters a roll. The use of moisture-proof paper packaging, are widely used in internal and external wall insulation, crack construction on the use of.

First of all, we introduce the raw materials: galvanized wire drawing wire when insulation raw materials, as shown: galvanized wire drawing, as the name suggests is about 200 wire galvanized wire drawn down from the wire diameter of conventional 0.32mm-1.8mm

Second, we look at the production of welded wire mesh machine Photo:

As we can see, the welded wire mesh fence is composed of the wire shaft and the weft wire arranged in the back of the mountain, and the welding is precision.

The figure is welded mesh production process in detail.

Thirdly, after the welded wire mesh is produced, the general volume is 200-300 meters. According to different customer requirements, we cut it into small rolls of ten to fifty meters to facilitate the transportation and use.

This figure is cut 18 meters long welded wire mesh.

Fourth, we use moisture-proof paper packaging, one is to facilitate storage, the second is to facilitate the transport.

Finally, the entire shipment, sending logistics. (Due to the amount of welding procurement generally larger, we generally use the logistics delivery)
The welded wire mesh production process is as follows:
1. The raw materials (low-carbon steel wire, galvanized wire straightening, iron wire, stainless steel wire) drawn into suitable for the production of different thickness of the wire diameter; (this process by the wire drawing plant to complete)
2. The production of raw materials used in a part of the shaft in the production of the shaft-shaped shaft, used as warp, the use of some of the raw silk as a weft, installed in the cyclone;
3.start the machine, precision row welding, pay attention to keep the mesh in the production of uniform, flat surface, to prevent leakage of the situation;
4. Will produce large welded wire mesh hot dip galvanized, cold galvanized or dip plastic processing. At the same time, according to the mark, the big roll is cut into small rolls of different meters (this procedure is finished by the surface treatment factory);
5 will do the surface treatment of welded wire mesh using moisture-proof packaging. Easy to transport and store.
6. Vehicle shipment, shipped to all parts of the country through logistics.
The above is the insulation welding wire production process.
Galvanized welded wire mesh welded wire mesh and the production process is similar, but added a galvanized and dip the surface treatment. The same is true of stainless steel welded wire mesh, using stainless steel wire as raw material.
