Glass balcony fence installation precautions

Glass balcony fence, giving a feeling of transparency, with decorative effect. As the balcony fence is not just decorative, more importantly, "security features", so the selection of balcony glass material to be properly installed properly, balcony glass is a force component, easily withstand the push and other external forces, the glass fence The glass used must have sufficient strength.

1, balcony fence glass surface installation points:

Balcony guardrail glass must be tempered glass or laminated glass, tempered glass thickness should not be less than 13 mm, the glass shall not be in direct contact with the rigid node, there should be elastic material between the two pads, when designed with both sides into the glass fence, Glass into the column notch both sides of the gap should be more than 3 mm, the gap filled with glass sealant, glass Xiang Xiang not less than 13 mm notch.

2, balcony guardrail glass base column installation points:

The base of the glass guardrail is the key part of the fixed guardrail, which needs to be assembled by the angle steel material into a fixed glass fixing part. Both sides of the fixing part are fixed with the expansion screw and the building floor or by welding and pre-connection, The bottom of the groove should be padded with a rubber bearing block with a hardness of 80-90. The depth of the glass extending into the fixture should be greater than 10 mm. The glass extends into both sides of the fixture (that is, between the angle steel and the steel plate) Clearance neoprene sheet liner, and the glass clamping, steel and glass need to set aside about 6 mm gap between the glass and other materials to be left at the intersection of about 6 mm gap, the gap with glass sealant Filling, installation is completed After the inspection confirmed that the security is not loose after the loose, the fence base surface decoration, it should be noted that the cover material shall not be in direct contact with the glass, the gap between the cover material and glass also need to use glass sealant filled.
