Installation of chain link fence

The following is the installation and construction requirements of the chain link fence.



1. The embedding of the column should be carried out in sections, firstly burying the columns at both ends, and then pulling the line to bury the intermediate column. From the longitudinal direction, the axis of the column should be on a straight line, and there should be no jagged phenomenon; from the height point of view, the top of the column should be smooth and there should be no unevenness.

2. The stadium fence should be implemented as soon as possible after the completion of the roadbed project; the contractor should formulate detailed construction organization design and submit it to the supervision engineer for approval before construction. The contractor shall, according to the approved construction organization design, carry out construction and lofting according to the requirements of the drawings and the actual terrain and features, and determine the centerline of the column.



3. When the drawings require that the columns, supports or anchor heads be buried in the concrete foundation, the contractor shall provide the necessary temporary cables or supports to hold the columns in place until the concrete hardens.



4. If there is a break in the stadium purse or at the intersection of the road, the spacing of the columns may be adjusted as needed. When crossing the river, when the width of the river is not more than 6M, it should be connected as shown in the drawings or with barbed wire; when the width of the river is greater than 6M, the stadium fence should be terminated and connected.



5. The mesh fence of the stadium that meets the requirements of size and model shall be firmly installed from the end of the column to the hook of the column according to the method specified in the drawings; or the mesh shall be installed in the frame, and the connection between the frame and the column shall be firm.



All mesh and wire shall be tight and not deformed, and the installation height shall comply with the drawings. After the installation of the stadium fence, the foundation of the column needs to be final compacted.
