The introduction of 358 fence

Fence name:

358 fence comes from its panel mesh opening 3" × 0.5" × 8 gauge - approximate

to 76.2mm × 12.7mm × 4mm mesh opening.High security fencing, as a kind of anti-climb and anti-cut fence barrier, is extremely difficult to penetrate or attack using conventional hand tools. The panels have small apertures which prevent foot and finger holds making it anti-climb with excellent visibility and resistance to vandalism. High weld strength at each intersection makes the fence strong and durable. It is designed to provide security and protection for industrial and commercial properties and public utilities. As well,it is suitable for military, airport, prison or security units, if together with electronic alarm and detection systems.

Production Description

Panel:

1.Material:Q235 Low carbon steel

2.Finish treatment:  hot dipped galvanized,PVC powder coated,PVC powder painting

2.Wire diameter:  horizontal and vertical wire both 4.0mm

3.Mesh size:  76.2mm*12.7mm(3”*0.5”)

4.Panel height:  from 2.0m to 5.2m,popular: 2500mm, 3000mm

5.Panel width:  2000mm-3000mm,popular: 2200mm, 3000mm

Post:

6.Post material:  high grade steel

7.Post size:  60*60mm,80*80mm or 120*60mm

8.Post thickness:  2.5mm to 5.0mm

9.Clamp bar:width same with post,M8 diameter screw.

Benefits:

Anti-climbing: more small openings, no toe or finger holds.

Anti-cut: robust wire and welded joints make cutting very difficult by bolt cutters and wire cutters.

High strength welded at each intersection.

Durable: covering Galfan and polymer powder coating ensure a long service life.

Mesh fencing specially configured to provide maximum visibility, especially used for emergency and electronic detection systems.
